# VeritasGraph — The Governed, On-Prem GraphRAG & Agent Framework

Stop chunking blindly. Combine Tree-Search structure with Knowledge-Graph reasoning — and wire it into governed AI agents. Runs 100% locally or in the cloud.

🎯 Traditional RAG guesses based on similarity. VeritasGraph reasons based on structure.Don't just find the document — understand the connection, then act on it with governed agents.

⭐ Star · 🍴 Fork · 💬 Discuss · 🐛 Report a bug

📚 Featured Guide — Build Governed AI Agents On-Prem

A complete walkthrough of designing, wiring, and shipping governed AI agents entirely on your own infrastructure.

📄 Read the guide: Build Governed AI Agents On-Prem (PDF)

▶️ Watch the walkthrough on YouTube

🚀 Quick Start (2 lines, no GPU)

pip install veritasgraph
veritasgraph demo --mode=lite

That's it — an interactive demo using cloud APIs (OpenAI/Anthropic), no local models required.

export OPENAI_API_KEY="sk-..."        # Lite: cloud APIs, zero setup
veritasgraph demo --mode=lite

veritasgraph demo --mode=local --model=llama3.2   # 100% offline with Ollama
veritasgraph start --mode=full                    # full GraphRAG pipeline

Useful links: ⚡ Live docs · 🎮 Live demo · 📖 Article · 📄 Research paper

🛠️ VeritasGraph Studio — Build, wire & test governed agents locally

Studio is a local Agent Build Workspace (FastAPI + single-page UI) that lets you build a knowledge graph from your own documents and wire it into agents alongside tools, memory, data logging, guardrails, and headroom-style context budgeting — then chat with those agents live and watch every stage of the orchestration pipeline. Everything runs 100% locally against Ollama.

🎮 Try the Studio Live — stable URL that always redirects to the current running studio tunnel.

Run it:

pip install -r requirements.txt
ollama serve & ollama pull qwen3:latest          # any local chat model
STUDIO_DATA_DIR="$PWD/studio_api/data" \
  uvicorn studio_api.main:app --host 127.0.0.1 --port 8200 --log-level warning
# Studio UI → http://localhost:8200/studio   ·   API docs → /docs

One-command end-to-end demo (builds a graph + drives a fully-wired agent through graph reasoning, memory recall, PII redaction, and a guardrail block):

python3 demos/agent-studio/sample_pipeline.py --model qwen3:latest

• 🧩 Knowledge Graph builder & explorer — ingest text, extract entities/relationships locally, inspect nodes/edges with grounded evidence.
• 🔎 Graph Q&A with citations — multi-hop answers backed by [doc#chunk] source attribution.
• 🤖 Agent workspace — create/edit agents with model selection, prompt/persona settings, and per-agent capability toggles.
• 🔀 Governed orchestration pipeline — per-turn flow of Guardrails → Memory → Knowledge Graph → Headroom budget → Tools → Data log, with full trace visibility.
• 🧰 Editable tools catalog — add, edit, enable/disable, test, and delete tools directly in Studio.
• 🌐 External real tool support — call real HTTP endpoints with configurable method, auth header, and custom headers.
• 🔌 MCP bridge integrations — local MCP proxy connectors (e.g. Chrome DevTools MCP, Unity MCP) with health-aware probing.
• 🛡️ Guardrails — PII redaction and policy-block controls with visible guardrail-block metrics.
• 🧠 Memory + Data logs — per-agent short-term memory and interaction-log persistence.
• 📈 Evaluation & fine-tune simulation — run eval suites, track pass-rate trends, and queue/monitor fine-tune jobs.
• 💬 Playground — run governed agent conversations live and inspect the pipeline trace.
• 📊 KPI dashboard — active agents, connected tools, eval pass rate, and guardrail-block counters.

See studio_api/README.md for API and architecture, and docs/STUDIO_ENTERPRISE_TEST.md for enterprise test scenarios.

🌳 + 🔗 Graph + Tree: the ultimate retrieval

Why choose? VeritasGraph includes the hierarchical "Table of Contents" navigation of PageIndex PLUS the semantic reasoning of a Knowledge Graph.

Document Root
├── [1] Introduction
│   ├── [1.1] Background ←── Tree Navigation
│   └── [1.2] Objectives
├── [2] Methodology ←───────── Graph Links
│   └── relates_to ──────────→ [3.1] Findings
└── [3] Results

📊 Feature comparison

🎬 See it in action

💡 What you're seeing: a query triggers multi-hop reasoning across the knowledge graph. Nodes light up as connections are discovered, showing exactly how the answer was found — not just what was found.

🔌 MCP Server — connect your IDE agent to VeritasGraph

VeritasGraph ships a dedicated Model Context Protocol server — the first zero-trust, air-gapped Enterprise GraphRAG server for MCP. Connect Claude Desktop, Cursor, VS Code, Windsurf, Cline, or Continue directly to the GraphRAG engine over JSON-RPC 2.0 stdio, with zero external data egress.

python -m veritasgraph_mcp     # from repo root (needs local Ollama for ingest/query)

Tools: veritasgraph_ingest_document, veritasgraph_query (multi-hop answers with [doc#chunk] citations), veritasgraph_search_entities, veritasgraph_get_graph, veritasgraph_clear_graph. See veritasgraph_mcp/README.md for IDE registration snippets.

📖 Python API

from veritasgraph import VisionRAGPipeline

pipeline = VisionRAGPipeline()                 # auto-detects available models
doc = pipeline.ingest_pdf("document.pdf")
result = pipeline.query("What are the key findings?")
print(result.answer)

from veritasgraph import VisionRAGPipeline

pipeline = VisionRAGPipeline()
doc = pipeline.ingest_pdf("report.pdf")

# View the document's hierarchical structure (like a Table of Contents)
print(pipeline.get_document_tree())
# Document Root
# ├── [1] Introduction (pp. 1-5)
# │   ├── [1.1] Background (pp. 1-2)
# │   └── [1.2] Objectives (pp. 3-5)
# └── [2] Methodology (pp. 6-15)

# Navigate to a specific section (tree-based retrieval)
section = pipeline.navigate_to_section("Methodology")
print(section['breadcrumb'])   # ['Document Root', 'Methodology']

# Or use graph-based semantic search
result = pipeline.query("What methodology was used?")
# → answer with section context: "📍 Location: Document > Methodology > Analysis Framework"

from veritasgraph import VisionRAGPipeline, VisionRAGConfig

config = VisionRAGConfig(ingest_mode="document-centric")  # tables stay intact!
pipeline = VisionRAGPipeline(config)
doc = pipeline.ingest_pdf("annual_report.pdf")

CLI

veritasgraph --version                                    # show version
veritasgraph info                                         # check dependencies
veritasgraph init my_project                              # initialize a project
veritasgraph ingest document.pdf --ingest-mode=document-centric   # Don't Chunk. Graph.
veritasgraph ingest https://youtube.com/watch?v=xxx       # auto-extract transcript
veritasgraph ingest https://example.com/article           # extract web article

Installation options

pip install veritasgraph            # basic (includes lite mode)
pip install veritasgraph[web]       # Gradio UI + visualization
pip install veritasgraph[graphrag]  # Microsoft GraphRAG integration
pip install veritasgraph[ingest]    # YouTube & web-article ingestion
pip install veritasgraph[all]       # everything

🏛️ Enterprise Compliance — VeritasGraph + VeritasReason

GraphRAG is brilliant at describing what your documents say. But enterprise questions like "Which purchase orders violated our Segregation-of-Duties policy last quarter?" are rule-evaluation problems over structured records — not similarity search.

For those, VeritasGraph ships a sister module: VeritasReason — a deterministic reasoning engine (forward-chaining + Rete + SPARQL) that fires policy rules over a triplet store and returns auditable answers with W3C PROV-O provenance.

 Policy PDFs ─┐                        ┌─ ingest_structured.py (SQL → triples + text)
              ▼                        ▼
      VeritasGraph GraphRAG      VeritasReason (TripletStore + RuleSet
      (quotes policy text)       + ForwardChainer + PROV-O)
              └──────────┬───────────────┘
                         ▼
             Compliance answer + violators table + clause citations

30-second smoke test (no install, stdlib only)

python tests/test_policy_compliance_demo.py

Seeds a fake ERP into a tiny in-memory triple store, evaluates four SoD rules from rules/sod_policy.yaml, and prints violators with citations:

✓ Reasoner fired. Detected 4 violation(s):
  po:PO-2204 SOD-01   Approved & paid by emp:E118
  po:PO-2301 SOD-02   Requested & approved by emp:E091
  po:PO-2317 SOD-03   $48,750.00 approved by emp:E091 (role:Manager, not Director)
  po:PO-2402 SOD-04   Vendor vendor:V77 related to approver emp:E140

Or install and run the packaged demo:

pip install veritas-reason
veritasreason-policy-demo

The same pattern applies to leave-policy violations (HRIS attendance), expense-report fraud (ledger + receipts), clinical protocol breaches (EHR + guidelines), or KYC/AML (transactions + watchlists). Define the SQL → triple mapping in ingest_structured.py, write rules in rules/*.yaml, and ask in plain English. See veritas-reason/plan.md for a full walk-through.

🔗 Interactive Graph Visualization

VeritasGraph includes an interactive 2D knowledge-graph explorer (PyVis) that visualizes entities and relationships in real time.

⚙️ Provider Support (OpenAI-compatible)

VeritasGraph works with any OpenAI-compatible API — mix and match cloud and local:

Also supported: Azure OpenAI, OpenRouter, Anyscale, LocalAI, vLLM.

cd graphrag-ollama-config
cp settings_openai.yaml settings.yaml
cp .env.openai.example .env       # edit with your provider settings
python -m graphrag.index --root . --config settings_openai.yaml
python app.py

⚠️ Embeddings must match your index. If you indexed with nomic-embed-text (768 dims), you must query with the same model — switching embedding models requires re-indexing. Full details in OPENAI_COMPATIBLE_API.md.

🐳 Deployment

Five-Minute Magic Onboarding (Docker)

Run a full stack (Ollama + Neo4j + Gradio) with one command:

cd docker/five-minute-magic-onboarding
# set your Neo4j password in .env, then:
docker compose up --build

Services: Gradio UI → http://127.0.0.1:7860 · Neo4j → http://localhost:7474 · Ollama → http://localhost:11434. See docker/five-minute-magic-onboarding/README.md.

Share with your team (free)

*Free tier has some limitations.

🏗️ Architecture

graph TD
    subgraph "Indexing Pipeline (one-time)"
        A[Source Documents] --> B{Document Chunking};
        B --> C{"LLM Extraction<br/>(Entities & Relationships)"};
        C --> D[Vector Index];
        C --> E[Knowledge Graph];
    end
    subgraph "Query Pipeline (real-time)"
        F[User Query] --> G{Hybrid Retrieval Engine};
        G -- "1. Vector search for entry points" --> D;
        G -- "2. Multi-hop graph traversal" --> E;
        G --> H{Pruning & Re-ranking};
        H -- "Rich context" --> I{LoRA-Tuned LLM Core};
        I -- "Answer + provenance" --> J{Attribution Layer};
        J --> K[Attributed Answer];
    end
    style A fill:#f2f2f2,stroke:#333,stroke-width:2px
    style F fill:#e6f7ff,stroke:#333,stroke-width:2px
    style K fill:#e6ffe6,stroke:#333,stroke-width:2px

The four stages:

1. Automated Knowledge Graph construction — chunk documents into TextUnits, extract (head, relation, tail) triplets, assemble nodes + edges in a graph DB (e.g. Neo4j).
2. Hybrid retrieval engine — vector search finds entry nodes, multi-hop traversal uncovers hidden relationships, pruning & re-ranking keeps the most relevant facts.
3. LoRA-tuned reasoning core — a locally hosted, LoRA-tuned open model generates attributed answers with efficient fine-tuning for reasoning + attribution.
4. Attribution & provenance layer — propagates source IDs, chunks, and graph nodes into a structured, traceable JSON output.

Hardware: 16+ CPU cores · 64GB+ RAM (128GB recommended) · NVIDIA GPU with 24GB+ VRAM (A100 / H100 / RTX 4090).Software: Docker & Docker Compose · Python 3.10+ · NVIDIA Container Toolkit.Copy .env.example → .env and populate with environment-specific values.

Why VeritasGraph?

• ✅ Fully on-premise & secure — 100% control over your data and models.
• ✅ Verifiable attribution — every claim traces back to its source.
• ✅ Advanced graph reasoning — answers complex, multi-hop questions.
• ✅ Hierarchical tree + graph — PageIndex-style TOC navigation with graph flexibility.
• ✅ Governed agents — guardrails, memory, tools, and context budgeting wired together in Studio.
• ✅ Open-source & sovereign — MIT-licensed, no vendor lock-in.

Who is it for? Engineers building enterprise search, compliance assistants, research copilots, scientific literature explorers, and agent memory systems — anywhere "the answer" depends on how facts connect, not just whether they appear near each other in a vector index.

🙌 Acknowledgments

Builds on the foundational work of HopRAG, Microsoft GraphRAG, LangChain & LlamaIndex, and Neo4j.

🏆 Awards & Citation

Presented at the International Conference on Applied Science and Future Technology (ICASF 2025) — 📄 Appreciation Certificate.

@article{VeritasGraph2025,
  title={VeritasGraph: A Sovereign GraphRAG Framework for Enterprise-Grade AI with Verifiable Attribution},
  author={Bibin Prathap},
  journal={International Conference on Applied Science and Future Technology (ICASF)},
  year={2025}
}

Star History

Licensed under MIT. ⭐ Star the repo to follow the roadmap for open-source, governed GraphRAG.
