A Claude Code plugin: 26-tool MCP server for editing tldraw .tldr files via JSON manipulation (headless, no browser needed), plus a tldraw-screenshot skill that renders a .tldr to PNG via tldraw.com so Claude can SEE the diagram.
Status
Working skeleton. Schema validation is wired (@tldraw/tlschema validators run before every write), fractional indexing uses @tldraw/utils, file writes are guarded by proper-lockfile. Output verified end-to-end against the real tldraw runtime via Store.loadStoreSnapshot() in the contract test layer.
Quick Start
Requires Node ≥ 20.
1. Install as a Claude Code plugin (one command registers the marketplace, the second installs the bundled MCP server + skill):
claude plugin marketplace add m9810223/tldraw-m9810223
claude plugin install tldraw-m9810223@tldraw-m9810223
Restart Claude Code. /mcp lists tldraw-m9810223 (26 tools); /plugin lists tldraw-m9810223; the tldraw-screenshot skill is available too.
If you'd rather wire just the MCP server (no skill), see Install / Update / Remove below.
2. Try the demo prompt in Claude Code:
Draw the Shai-Hulud supply-chain attack flow described in this article with MCP `tldraw-m9810223`, save to `./demo.tldr`:
https://semgrep.dev/blog/2026/malicious-dependency-in-pytorch-lightning-used-for-ai-training/
- Match the actors and how data/control flows between them
- Polish the result at the end
3. View the result — drop ./demo.tldr onto tldraw.com, or use the tldraw VS Code extension for live preview.
Source file: docs/demo.tldr
Tools
File / page lifecycle
| Tool | What it does |
|---|---|
create_empty_file |
Create a fresh .tldr with a default page |
create_page |
Add a new page |
list_pages |
List pages with id, name, ordering index |
move_to_page |
Move shapes; bindings: 'error' | 'pull' | 'cut' controls binding handling |
Shapes
| Tool | What it does |
|---|---|
create_rect |
Create a rectangle (geo shape) |
create_text |
Create a text shape |
create_group |
Group shapes by reparenting them |
ungroup |
Dissolve a group, reparenting its children to the group's parent |
connect |
Arrow + bindings between two same-page shapes |
list_shapes |
List shapes — id, type, x, y, label only |
get_shape |
Full record of one shape by id |
update_shape |
Shallow-merge patch (use nested { "props": {...} } for prop edits) |
delete_shape |
Delete by id; cascade: true (default) also removes attached arrows + bindings |
Layout / text fitting
| Tool | What it does |
|---|---|
fit_to_text |
Resize a geo/text shape to fit its current text content |
align |
Align shapes on an axis (left/right/top/bottom/center-x/center-y) |
distribute |
Even-space shapes between the outermost two |
auto_layout |
Lay shapes out in a horizontal/vertical chain |
graph_layout |
Dagre layout for arrow-connected shapes (best for non-chain topologies) |
measure_arrow_labels |
Report label sizes + endpoint distances for labeled arrows |
bend_overlapping_arrows |
Bend parallel arrows (same shape pair) symmetrically; priority[] keeps important arrows straight. graph_layout calls this automatically. |
polish_layout |
One-shot finisher: fit_to_text every node + graph_layout (auto-bends arrows). Use as the last step after building a fresh diagram. |
Discovery & escape hatch
| Tool | What it does | Token cost |
|---|---|---|
search_api |
List supported shape types + curated required props. Pass {type, verbose:true} to dump live prop names from @tldraw/tlschema for any type (including ones not in the curated list) |
low / medium |
exec_jq |
Run a jq filter against the file. write=true persists (auto-checkpoint first) |
varies |
Checkpoints (safety)
| Tool | What it does | Token cost |
|---|---|---|
save_checkpoint |
Copy .tldr to a timestamped backup |
low |
list_checkpoints |
List backups, newest first | low |
restore_checkpoint |
Restore a backup (most recent if checkpoint omitted) |
low |
The token-saving design: tools take primitive args, return ids or ok. The full JSON only enters context when you call get_shape deliberately.
Install / Update / Remove
jq only needed for exec_jq (brew install jq / apt-get install jq).
As a plugin (recommended — bundles MCP server + skill)
# Install (user scope by default)
claude plugin marketplace add m9810223/tldraw-m9810223
claude plugin install tldraw-m9810223@tldraw-m9810223
# Update
claude plugin update tldraw-m9810223
# Remove
claude plugin uninstall tldraw-m9810223
claude plugin marketplace remove tldraw-m9810223
rm -rf ~/.claude/plugins/cache/tldraw-m9810223 # optional — also drop the cached clone
# Verify clean (both should print nothing)
claude plugin list | grep tldraw
claude mcp list | grep -i tldraw
MCP server only (no skill)
Use this if you want the editing tools but not the screenshot skill, or you're on a Claude client that doesn't speak Code's plugin system.
# Install — user scope: every project on this machine
claude mcp remove tldraw-m9810223 -s user 2>/dev/null; rm -rf ~/.npm/_npx
claude mcp add -s user tldraw-m9810223 -- npx -y github:m9810223/tldraw-m9810223
# Install — local scope (default): only the current project directory
claude mcp remove tldraw-m9810223 2>/dev/null; rm -rf ~/.npm/_npx
claude mcp add tldraw-m9810223 -- npx -y github:m9810223/tldraw-m9810223
The first arg (tldraw-m9810223) is the local server name — pick whatever you like, then refer to it the same way in subsequent commands. Restart Claude Code, then /mcp lists it with 26 tools.
Wire up to other MCP clients
Same JSON shape, different config file location:
| Client | Config path |
|---|---|
| Claude Desktop | ~/Library/Application Support/Claude/claude_desktop_config.json (macOS) |
| Cursor | ~/.cursor/mcp.json |
| VS Code | .vscode/mcp.json |
Bootstrapping a .tldr file
Use the create_empty_file tool, or save an empty canvas from tldraw.com and point tools at the absolute path.
create_empty_file({ file: "/tmp/demo.tldr" })
Viewing / editing the output
| Tool | Notes |
|---|---|
tldraw-screenshot skill (bundled) |
Programmatic render to PNG via playwright-cli + tldraw.com. Triggers automatically when Claude wants to see a .tldr |
| tldraw.com | Drag the .tldr file onto the page |
| tldraw VS Code extension | Native .tldr preview + edit inside VS Code; survives file changes from the MCP server |
| Tldraw Desktop / official editor | Drop the file in |
The VS Code extension is the smoothest dev loop — keep code path/to/file.tldr open in a tab while the MCP edits it; the editor refreshes on disk change.
The tldraw-screenshot skill is the smoothest agent loop — Claude edits via the MCP, renders via the skill, looks at the PNG, edits again. See skills/tldraw-screenshot/SKILL.md for the workflow and gotchas. Requires playwright-cli on PATH.
Design comparison vs official tldraw-mcp-app
The Cloudflare-hosted official MCP exposes only search + exec (run any JS in a live tldraw Editor). This skeleton goes the opposite way — typed JSON edits over .tldr files — and borrows the discovery pattern (search_api) and escape hatch (exec_jq) so an LLM can fall through when typed tools don't cover an operation.
Official tldraw-mcp-app |
This skeleton | |
|---|---|---|
| Transport | streamable-http + sse (Cloudflare) | stdio (works in Claude Code directly) |
| Runtime | Real tldraw Editor in widget iframe | Pure Node, edits raw JSON |
| Tools | 2 (search, exec) + checkpoints |
26: file/page (4) + shape (9) + layout (8) + discovery (2) + ckpt (3) |
| Live preview | Yes (widget iframe) | No (open the file in tldraw to view) |
| Coverage | Whole Editor API | Geo / text / arrow + jq escape hatch |
Known gaps
index(z-order) only supports appending above the current max — no insert-between- No image / video / asset support
- Schema version pinning is informational only — opening a file in a newer tldraw may trigger migrations
search_apicurated list is hand-maintained alongside the live@tldraw/tlschemareflection
Architecture
.claude-plugin/
plugin.json Plugin metadata + pointers to mcpServers + skills
marketplace.json Marketplace manifest so `claude plugin install` can find this
.mcp.json Plugin-scoped MCP server declaration (npx-from-github)
skills/
tldraw-screenshot/
SKILL.md Workflow for rendering .tldr → PNG via playwright-cli + tldraw.com
src/
index.ts MCP server entry, tool registration (stdio transport)
tools.ts Tool handlers + zod input schemas
shapes.ts tldraw record factories (geo/text/arrow/group/binding)
store.ts Load/save .tldr + withFileLock; helpers (id gen, indexing, find, page-of-shape, bindings-for-shape)
template.ts Empty .tldr generator using @tldraw/tlschema serialize()
validate.ts validateShape / validateBinding using createShapeValidator + createBindingValidator
checkpoint.ts Timestamped backups under .tldraw-mcp-checkpoints/
jq.ts Shell-out to jq for the exec_jq escape hatch
text-metrics.ts Text size heuristics for autoFit + label measurement
graph-layout.ts Dagre wrapper for graph_layout
arrow-bending.ts Detect parallel-edge overlap + assign symmetric bend values
test/
unit/ store + validate + text-metrics + arrow-bending (34 tests)
integration/ tools end-to-end on tmp .tldr (39 tests)
contract/ loadStoreSnapshot against real @tldraw/store (4 tests)
boundary/ N-1 / N / N+1 limits + concurrent writes (89 tests)
Pure JSON manipulation — no @tldraw/store, no DOM, no React.
